Mean Well
-
-
Mean Well 24vx4.16a Constant Voltage Drivers LPV-100-24 IP67
Regular price
₹2,413
Regular price
Sale price
₹2,413
Incl. all taxes • Shipping calculated at checkout.
Free delivery on orders above ₹3,000 · Delivery charges
Price excl. GST
₹2,044.92
GST @ 18% included in above product price
1-year manufacturer warranty · Burnt or wiring damage not covered · Warranty terms
🚚 Delivery in 2-3 days (Delhi NCR, UP & Haryana), 5-6 days elsewhere
Works well with
Mean Well APV-35-24 24V 1.5A 35W LED Power Supply
₹1,145
Mean Well APV-8-24 24V 0.34A 8W LED Driver
₹508
Unison 101 ZDA 48 25 01, SSR DC to AC, 25 Amp
₹302
Unison 901 ZDA 48 25 01 AL5, SSR DC to AC, 25 Amp
₹450
Selec UNIX-1-230V, PLC
₹4,490
Unison 101 ZDA 60 40 01, SSR DC to AC, 40 Amp
₹454
Description
LPV-100-24, an enclosed power supply from Mean Well, rated 24 VDC output at 4.16 AMP, 100.8W output power.
Output voltage
24 VDC
Output current
4.16 AMP
Power
100.8W
Input voltage
90 to 264V AC 127 to 370V DC
Technical specifications
| Make | Mean Well |
| Model | LPV-100-24 |
| Output voltage | 24 VDC |
| Output current | 4.16 AMP |
| Input voltage | 90 to 264V AC 127 to 370V DC |
| Features | Water Proof |
| Shape | Linear |
| Type of Item | Constant Voltage Drivers |
| Warranty | 2 Years |
| IP Rating | IP67 |
| Product Dimensions in MM | 190*52*37mm |
| Product Weight (kg) | 0.63Kg |
| Driver Efficiency | 0.88 |
| Driver Ripple | 150-mvp-p |
| Length | 190mm |
| Width | 52mm |
| Height | 37mm |
| Operating Temperature | -25 ~ +70 |
| Master Box | 20 PCS |
Frequently asked questions about the Mean Well LPV-100-24
What is the output of the Mean Well LPV-100-24?
The LPV-100-24 is rated 24 VDC output, output current 4.16 AMP, 100.8W.
What input voltage does the LPV-100-24 accept?
The LPV-100-24 accepts an input of 90 to 264V AC 127 to 370V DC, as listed on this page.
What is the operating temperature range of the LPV-100-24?
The listed operating temperature range is -25 ~ +70.
What warranty does the LPV-100-24 come with?
This product is listed with a 2 Years warranty.
What is the IP rating of the LPV-100-24?
The LPV-100-24 is listed as IP67.
Where can I download the LPV-100-24 datasheet?
You can download it from the datasheet section on this page: LPV-100-24 datasheet.
Is the LPV-100-24 genuine, and do you provide a GST invoice?
Yes. Voltkart is an authorised dealer of Mean Well, so you receive genuine Mean Well products, and every order comes with a GST invoice.
Can I order the LPV-100-24 in bulk for OEM or wholesale use?
Yes, please send your quantity through our wholesale enquiry page or message us on WhatsApp 8800754881, and our team will help with a quote.
Compare and explore more Mean Well products
- LPV-100-12 - 12 VDC at 8.3 AMP
Comparing 24V power supplies? See every model from 10 W to 960 W in the 24V SMPS price list.
Need help choosing the right model?
Voltkart is an authorised dealer of Mean Well. Share your load details and we will help you pick the correct power supply.
