Mean Well LRS-50-48 48V 1.1A 52.8W Enclosed SMPS Power Supply
Regular price
₹1,058
Regular price
₹1,860
Sale price
₹1,058
Incl. all taxes • Shipping calculated at checkout.
Price excl. GST
₹896.61
GST @ 18% included in above product price
Authorized Dealer
GST Invoice
PAN India Delivery
Fast Dispatch
🚚 Delivery in 2-3 days (Delhi NCR, UP & Haryana), 5-6 days elsewhere
Works well with
Mean Well LRS-100-48 SMPS - 48V 2.3A - 102W Metal Power Supply
₹1,487
Mean Well EDR-120-48 48V 2.5A 120W DIN Rail Power Supply
₹2,351
Mean Well LRS-150-48 SMPS - 48V 3A - 150W Metal Power Supply
₹1,966
Unison 101 ZDA 48 25 01, SSR Dc to Ac, 25amp
₹302
Unison 901 ZDA 48 25 01 AL5, SSR Dc to Ac, 25amp
₹450
Selec UNIX-1-230V, PLC
₹4,490
Description
LRS-50-48, an enclosed power supply from Mean Well, rated 48 VDC output at 1.1 AMP, 52.8W output power.
Output voltage
48 VDC
Output current
1.1 AMP
Power
52.8W
Input voltage
85 to 264V AC 120 to 373V DC
Technical specifications
| Make | Mean Well |
| Model | LRS-50-48 |
| Output voltage | 48 VDC |
| Output current | 1.1 AMP |
| Input voltage | 85 to 264V AC 120 to 373V DC |
| Product Category | Switching Power Supplies |
| Output Voltage-Channel 1 | 48 VDC |
| Number of Outputs | 1 Output |
| Open Frame/Enclosed | Enclosed |
| Output Current-Channel 1 | 1.1 A |
| Industry | Industrial |
| Mounting Style | Panel |
| Length | 99 mm |
| Width | 82 mm |
| Height | 30 mm |
| Input Frequency | 47 Hz to 63 Hz |
| Packaging | Bulk |
| Subcategory | AC-DC Power Supply |
| Unit Weight | 230 g |
Notable features
- LRS-50-48 Datasheet
Frequently asked questions about the Mean Well LRS-50-48
What is the output of the Mean Well LRS-50-48?
The LRS-50-48 is rated 48 VDC output, output current 1.1 AMP, 52.8W.
What input voltage does the LRS-50-48 accept?
The LRS-50-48 accepts an input of 85 to 264V AC 120 to 373V DC, as listed on this page.
How is the LRS-50-48 mounted?
Mounting style: Panel.
Where can I download the LRS-50-48 datasheet?
You can download it from the datasheet section on this page: LRS-50-48 datasheet.
Is the LRS-50-48 genuine, and do you provide a GST invoice?
Yes. Voltkart is an authorised dealer of Mean Well, so you receive genuine Mean Well products, and every order comes with a GST invoice.
Can I order the LRS-50-48 in bulk for OEM or wholesale use?
Yes, please send your quantity through our wholesale enquiry page or message us on WhatsApp 8800754881, and our team will help with a quote.
Compare and explore more Mean Well products
- LRS-50-24 - 24 VDC at 2.2 AMP
- LRS-50-12 - 12 VDC at 4.2 AMP
- LRS-50-5 - 5 VDC at 10 AMP
- LRS-50-15 - 15 VDC at 3.4 AMP
Need help choosing the right model?
Voltkart is an authorised dealer of Mean Well. Share your load details and we will help you pick the correct power supply.
