SELEC
SELEC VAF391, 96*96 Digital panel meter- Voltage, Ampere & frequency
No reviews
Regular price
Rs. 1,064.00
Regular price
Rs. 1,918.00
Sale price
Rs. 1,064.00
Excl. GST: Rs. 901.69
Taxes included.
Shipping calculated at checkout.
🚚 Delivered within 5 to 7 Days
Couldn't load pickup availability
Digital Multifunction Meter with LED display, Measures Voltage, Current, Frequency, Power and Power Factor
BRIEF SPECIFICATIONS
| Display Type | 7 Segment LED |
| Display Configuration | 3 Rows of 3 Digits |
| Electrical Connection | 3Ø -3W, 3Ø - 4W, 2Ø - 3W, 1Ø - 2W |
| Features | VAF meter with Power-Factor and Power, Run Hour and RPM measurement |
| Communication Protocol | NA |
| CT Primary | 1 / 5A to 10kA (Programmable for Any Value) |
| CT Secondary | 1 / 5 A (Programmable) |
| PT Primary | 100V to 500kV (Programmable for Any Value) |
| PT Secondary | 100V to 500V (Programmable for Any Value) |
| Rated Input Current | Nominal 5A AC (Min - 20mA Max - 6A) |
| Size | 96 x 96mm |
| Supply Voltage | 85 to 270V AC (45/65Hz) |
| Mounting Type | Panel Mount |
| Certification | -- |
