SELEC
Selec VAF391, 96*96 Digital panel meter- Voltage, Ampere & frequency
Regular price
₹1,245
Regular price
₹2,110
Sale price
₹1,245
Incl. all taxes • Shipping calculated at checkout.
Free delivery on orders of ₹3,001+. Below that, delivery is ₹160 (₹99 to Delhi, UP, Haryana and HP on orders of ₹1,000+).
Price excl. GST
₹1,055.08
GST @ 18% included in above product price
Authorized Dealer
GST Invoice
PAN India Delivery
Fast Dispatch
🚚 Delivery in 2-3 days (Delhi NCR, UP & Haryana), 5-6 days elsewhere
Works well with
Selec VAF39A-1-230V, Digital Panel meter-voltage, ampere & frequency
₹1,323
Selec MV305, 96*96 Digital Volt meter
₹550
Selec MV205, 72*72 Digital Volt meter
₹550
Selec MV15, 48*96 Digital Volt meter
₹550
Selec MA302, 96*96 Digital Panel Ampere amp meter
₹526
Description
VAF391, a digital panel meter from Selec. Digital Multifunction Meter with LED display, Measures Voltage, Current, Frequency, Power and Power Factor.
Supply Voltage
85 to 270V AC (45/65Hz)
Display Type
7 Segment LED
Size
96 x 96mm
Mounting Type
Panel Mount
Technical specifications
| Make | Selec |
| Model | VAF391 |
| Display Type | 7 Segment LED |
| Display Configuration | 3 Rows of 3 Digits |
| Electrical Connection | 3Ø -3W, 3Ø - 4W, 2Ø - 3W, 1Ø - 2W |
| CT Primary | 1 / 5A to 10kA (Programmable for Any Value) |
| CT Secondary | 1 / 5 A (Programmable) |
| PT Primary | 100V to 500kV (Programmable for Any Value) |
| PT Secondary | 100V to 500V (Programmable for Any Value) |
| Rated Input Current | Nominal 5A AC (Min - 20mA Max - 6A) |
| Size | 96 x 96mm |
| Supply Voltage | 85 to 270V AC (45/65Hz) |
| Mounting Type | Panel Mount |
Notable features
- Features: VAF meter with Power-Factor and Power, Run Hour and RPM measurement
More about the VAF391
Digital Multifunction Meter with LED display, Measures Voltage, Current, Frequency, Power and Power Factor
Frequently asked questions about the Selec VAF391
What is the VAF391?
Digital Multifunction Meter with LED display, Measures Voltage, Current, Frequency, Power and Power Factor. It is a digital panel meter made by Selec.
What is the supply voltage of the VAF391?
The VAF391 is listed with supply voltage of 85 to 270V AC (45/65Hz).
What is the display type of the VAF391?
The VAF391 is listed with display type of 7 Segment LED.
What is the size of the VAF391?
The VAF391 is listed with size of 96 x 96mm.
Where can I download the VAF391 datasheet?
You can download it from the datasheet section on this page: VAF391 datasheet.
Is the VAF391 genuine, and do you provide a GST invoice?
Yes. Voltkart is an authorised dealer of Selec, so you receive genuine Selec products, and every order comes with a GST invoice.
Can I order the VAF391 in bulk for OEM or wholesale use?
Yes, please send your quantity through our wholesale enquiry page or message us on WhatsApp 8800754881, and our team will help with a quote.
Explore more Selec products
Need help choosing the right model?
Voltkart is an authorised dealer of Selec. Share your application details and we will help you pick the correct model.
Compare all digital amp meters, volt meters and VAF meters with prices →
