Multi Output SMPS (Dual, Triple & Quad)
Multi-output SMPS on Voltkart: 21 Mean Well dual, triple and quad output power supplies (RD, RT and RQ series) from ₹1,382 including GST. Voltkart is an authorised Mean Well distributor.
Multi-output power supplies give several DC voltages from one enclosed unit, such as 5 V + 12 V or ±12 V, for instruments, test equipment, controllers and machines. Prices checked 17 November 2026. Reviewed by Amit, Voltkart.
Mean Well multi-output SMPS (live prices)
| Model | Outputs | Voltage and current | Price (incl. GST) |
|---|---|---|---|
| Mean Well RD-35A | Dual (2) | 5 V 4 A, 12 V 1 A | ₹1,382 |
| Mean Well RD-35B | Dual (2) | 5 V 2.2 A, 24 V 1 A | ₹1,382 |
| Mean Well RD-50A | Dual (2) | 5 V 6 A, 12 V 2 A | ₹1,868 |
| Mean Well RD-50B | Dual (2) | 5 V 4 A, 24 V 1.4 A | ₹1,868 |
| Mean Well RD-65A | Dual (2) | 5 V 6 A, 12 V 3 A | ₹1,912 |
| Mean Well RD-65B | Dual (2) | 5 V 4 A, 24 V 2 A | ₹1,912 |
| Mean Well RD-125-1224 | Dual (2) | 12 V 3.7 A, 24 V 3.7 A | ₹3,024 |
| Mean Well RD-125B | Dual (2) | 5 V 4.6 A, 24 V 4.6 A | ₹3,186 |
| Mean Well RD-125A | Dual (2) | 5 V 7.7 A, 12 V 7.7 A | ₹3,186 |
| Mean Well RT-50A | Triple (3) | 5 V 4 A, 12 V 2 A, -5 V 0.5 A | ₹1,706 |
| Mean Well RT-65D | Triple (3) | 5 V 4 A, 24 V 1.5 A, 12 V 1 A | ₹2,106 |
| Mean Well RT-125B | Triple (3) | 5 V 12 A, 12 V 5 A, -12 V 1 A | ₹3,078 |
| Mean Well RT-125C | Triple (3) | 5 V 10 A, 15 V 4.5 A, -15 V 1 A | ₹3,078 |
| Mean Well RT-125D | Triple (3) | 5 V 8 A, 24 V 3 A, 12 V 2 A | ₹3,078 |
| Mean Well RQ-65B | Quad (4) | 5 V 6 A, 12 V 2 A, -5 V 0.5 A, -12 V 0.5 A | ₹2,214 |
| Mean Well RQ-65D | Quad (4) | 5 V 4 A, 12 V 1.5 A, 24 V 1 A, -12 V 0.5 A | ₹2,214 |
| Mean Well RQ-85C | Quad (4) | 5 V 7 A, 15 V 2.5 A, -5 V 0.5 A, -15 V 0.5 A | ₹2,970 |
| Mean Well RQ-125B | Quad (4) | 5 V 11 A, 12 V 4.5 A, -5 V 1 A, -12 V 0.5 A | ₹3,402 |
| Mean Well RQ-125D | Quad (4) | 5 V 8 A, 12 V 2.5 A, 24 V 2 A, -12 V 0.5 A | ₹3,402 |
For single-output supplies see the Mean Well range or the Mean Well SMPS price list.
Frequently asked questions
What is a multi-output SMPS?
A single power supply with two, three or four isolated or common-ground DC outputs, for example 5 V for logic and 12 V or 24 V for relays and fans. It saves panel space and wiring compared with separate supplies.
What do the A, B, C and D suffixes mean?
They select the output voltages. For example RD-65A gives 5 V and 12 V, RD-65B gives 5 V and 24 V, and the triple-output RT-65C gives 5 V, +15 V and -15 V. Check the voltages in the table before ordering.
Can I take full current from every output at once?
Not always. The total load must stay within the supply’s rated wattage, and each output has its own maximum current. Mean Well’s datasheet lists the allowed combinations.
Not sure which voltages you need? WhatsApp 8800754881 (Mon–Sat, 12:30–7 pm). GST invoice on every order, delivery across India.
19 products
Need bulk quantities or project pricing? Get exclusive rates on large orders.
WhatsApp Us-
Mean Well RD-35A 32W Dual Output 5V 4A, 12V 1A
No reviewsRegular price ₹1,382Regular priceSale price ₹1,382In stock · Fast dispatch
-
Mean Well RQ125D 125W Quad Output SMPS 5V 8A, 12V 2.5A, 24V 2A, -12V 0.5A
No reviewsRegular price ₹3,402Regular priceSale price ₹3,402In stock · Fast dispatch
-
Mean Well RQ125B 125W Quad Output SMPS 5V 11A, 12V 4.5A, -5V 1A, -12V 0.5A
No reviewsRegular price ₹3,402Regular priceSale price ₹3,402In stock · Fast dispatch
-
Mean Well RQ-85C 85W Quad Output 5V 7A, 15V 2.5A, -5V 0.5A, -15V 0.5A
No reviewsRegular price ₹2,970Regular priceSale price ₹2,970In stock · Fast dispatch
-
Mean Well RQ-65D 65W Quad Output 5V 4A, 12V 1.5A, 24V 1A, -12V 0.5A
No reviewsRegular price ₹2,214Regular priceSale price ₹2,214In stock · Fast dispatch
-
Mean Well RQ-65B 62.5W Quad Output 5V 6A, 12V 2A, -5V 0.5A, -12V 0.5A
No reviewsRegular price ₹2,214Regular priceSale price ₹2,214In stock · Fast dispatch
-
Mean Well RT-125D 136W Triple Output 5V 8A, 24V 3A, 12V 2A
No reviewsRegular price ₹3,078Regular priceSale price ₹3,078In stock · Fast dispatch
-
Mean Well RT-125C 132.5W Triple Output 5V 10A, 15V 4.5A, -15V 1A
No reviewsRegular price ₹3,078Regular priceSale price ₹3,078In stock · Fast dispatch
-
Mean Well RT-125B 132W Triple Output 5V 12A, 12V 5A, -12V 1A
No reviewsRegular price ₹3,078Regular priceSale price ₹3,078In stock · Fast dispatch
-
Mean Well RT-65D 65W Triple Output 5V 4A, 24V 1.5A, 12V 1A
No reviewsRegular price ₹2,106Regular priceSale price ₹2,106In stock · Fast dispatch
-
Mean Well RT-50A 46W Triple Output 5V 4A, 12V 2A, -5V 0.5A
No reviewsRegular price ₹1,706Regular priceSale price ₹1,706In stock · Fast dispatch
-
Mean Well RD-65B 68W Dual Output 5V 4A, 24V 2A
No reviewsRegular price ₹1,912Regular priceSale price ₹1,912In stock · Fast dispatch
-
Mean Well RD-65A 65W Dual Output 5V 6A, 12V 3A
No reviewsRegular price ₹1,912Regular priceSale price ₹1,912In stock · Fast dispatch
-
Mean Well RD-35B 35W Dual Output 5V 2.2A, 24V 1A
No reviewsRegular price ₹1,382Regular priceSale price ₹1,382In stock · Fast dispatch
-
Mean Well RD-125-1224 133W Dual Output 12V 3.7A, 24V 3.7A
No reviewsRegular price ₹3,024Regular priceSale price ₹3,024In stock · Fast dispatch
-
Mean Well RD-125A 125W Dual Output 5V 7.7A, 12V 7.7A
No reviewsRegular price ₹3,186Regular priceSale price ₹3,186In stock · Fast dispatch
-
Mean Well RD-125B AC-DC Power Supply | Multi-Voltage Output 5V-4.6AMP & 24V-4.6AMP
No reviewsRegular price ₹3,186Regular priceSale price ₹3,186In stock · Fast dispatch
-
Mean Well RD-50B AC-DC Power Supply | Multi-Voltage Output 5V-4AMP & 24V-1.4AMP
1 reviewRegular price ₹1,868Regular priceSale price ₹1,868In stock · Fast dispatch
-
Mean Well RD-50A AC-DC Power Supply | Multi-Voltage Output 5V-6AMP & 12V-2AMP
No reviewsRegular price ₹1,868Regular priceSale price ₹1,868In stock · Fast dispatch
