Schneider CA2KN31M7 Control Relay 3NO+1NC, coil voltage 220vac, TeSys K

Q: What is the contactor application of the CA2KN31M7?

Control circuit, as published by Schneider Electric.

Q: What is the uc control circuit voltage of the CA2KN31M7?

220...230 V AC 50/60 Hz, as published by Schneider Electric.

Q: What is the pole contact composition of the CA2KN31M7?

3 NO + 1 NC, as published by Schneider Electric.

Q: Where can I download the CA2KN31M7 datasheet?

You can download the official PDF datasheet here: CA2KN31M7 datasheet (PDF) on this page.

Q: Is the CA2KN31M7 genuine, and do you provide a GST invoice?

Yes. Voltkart stocks genuine Schneider Electric products, and every order comes with a GST invoice.

Q: Can I order the CA2KN31M7 in bulk for OEM or panel-building use?

Yes, please send your quantity through our wholesale enquiry page or message us on WhatsApp 8800754881, and our team will help with a quote.

Rs. 1,969.00

~~Rs. 3,090.00~~ Rs. 1,969.00

36% off

Incl. all taxes • Shipping calculated at checkout.

Price excl. GST Rs. 1,668.64

GST @ 18% included in above product price

Quantity

GST Invoice PAN India Delivery Fast Dispatch

Need bulk pricing? Get exclusive rates for large orders

Chat on WhatsApp Request a formal quote

🚚 Delivery in 2-3 days (Delhi NCR, UP & Haryana), 5-6 days elsewhere

Check delivery date

Works well with

Schneider LC1D09, 9Amp Contactor Rs. 1,421

Schneider LC1E1810, 18Amp Contactor, coil voltage 220vac Rs. 1,400

Schneider LRE22 Over Load Relay Rs. 2,030

Schneider LC1D40, 40Amp Contactor Rs. 6,830

Description

CA2KN31M7 is a Schneider Electric TeSys K control relay. Schneider lists it as: TeSys K control relay - 3 NO + 1 NC - <= 690 V - 220...230 V AC coil.

Contactor application

Control circuit

Uc control circuit voltage

220...230 V AC 50/60 Hz

Pole contact composition

3 NO + 1 NC

Utilisation category

AC-15

Technical specifications

Make	Schneider Electric
Model	CA2KN31M7
Product name	TeSys CAK
Product or component type	Control relay
Contactor application	Control circuit
Utilisation category	AC-15; DC-13
Pole contact composition	3 NO + 1 NC
Ue rated operational voltage	<= 690 V <= 400 Hz
Control circuit type	AC at 50/60 Hz
Uc control circuit voltage	220...230 V AC 50/60 Hz
Ith conventional free air thermal current	10 A (at 50 °C)
Ui rated insulation voltage	690 V conforming to IEC 60947; 750 V conforming to VDE 0110 group C
Mounting support	Plate; Rail
Connections - terminals	Screw clamp terminals 1 cable(s) 1.5…4 mm²solid; Screw clamp terminals 2 cable(s) 1.5…4 mm²solid
Operating time	10...20 ms coil de-energisation and NO opening; 10...20 ms coil energisation and NO closing
Mechanical durability	10 Mcycles
Maximum operating rate	10000 cyc/h
Height	58 mm
Width	45 mm
Depth	57 mm
Net weight	0.18 kg
Standards	EN/IEC 60947-5-1; GB/T 14048.5; UL 60947-5-1; CSA C22.2 No 60947-5-1
Product certifications	CB Scheme; CCC; UL; CSA
IP degree of protection	IP2X
Ambient air temperature for operation	-25…50 °C
