Schneider Electric LRD06 Thermal Overload Relay 1–1.6A | TeSys D Motor Protection Relay
The Schneider Electric LRD06 Thermal Overload Relay is a high-performance motor protection device designed to safeguard three-phase motors against overload, phase failure, and prolonged overcurrent conditions. Part of the trusted TeSys D Series, the LRD06 features an adjustable current range of 1–1.6A, making it ideal for protecting low-power motors in industrial automation, machinery, and electrical control panels.
Designed to work seamlessly with Schneider Electric LC1D09 to LC1D38 contactors, the LRD06 forms a complete Direct-On-Line (DOL) motor starter solution. Its Class 10A tripping characteristic allows motors to withstand normal starting currents while providing fast and reliable protection against sustained overloads. The relay also offers phase-loss sensitivity, helping prevent costly motor damage caused by single phasing or unbalanced loads.
The compact design enables quick installation beneath compatible TeSys D contactors, while manual and automatic reset options provide flexibility for different industrial applications. Whether you're protecting motors in pumps, compressors, conveyors, fans, or manufacturing equipment, the Schneider LRD06 delivers dependable motor protection and helps reduce maintenance costs and unexpected downtime.
Key Features
• Genuine Schneider Electric TeSys D Series Thermal Overload Relay
• Adjustable current setting: 1–1.6A
• Class 10A thermal tripping characteristic
• Protects against motor overload and phase failure
• Manual and automatic reset selection
• Built-in trip indication for easy troubleshooting
• Direct mounting on Schneider TeSys D contactors
• Compact, rugged, and maintenance-friendly design
• High reliability for industrial motor protection
Technical Specifications
• Model: LRD06
• Brand: Schneider Electric
• Series: TeSys D
• Product Type: Thermal Overload Relay
• Adjustable Current Range: 1–1.6A
• Tripping Class: Class 10A
• Number of Poles: 3 Pole
• Reset Type: Manual / Automatic
• Mounting: Direct Mount on LC1D Series Contactors
• Compatible Contactors: LC1D09, LC1D12, LC1D18, LC1D25, LC1D32 & LC1D38
• Standards: IEC 60947-4-1
Applications
• Motor Control Centers (MCC Panels)
• Three-phase motor starters
• Industrial control panels
• Pump control systems
• Compressors and HVAC equipment
• Conveyor systems
• Packaging and processing machinery
• Manufacturing plants
• PLC-based automation systems
• OEM machine panels
Why Buy From Voltkart?
• Genuine Schneider Electric products
• GST invoice provided with every order
• Pan India delivery in 5–7 days
• Bulk pricing available on WhatsApp
• Expert technical support for product selection
Frequently Asked Questions
Q: What motors is the Schneider LRD06 suitable for?
A: The LRD06 is designed to protect three-phase motors with a full-load current adjustable between 1A and 1.6A, ensuring accurate thermal overload protection.
Q: Which Schneider contactors are compatible with the LRD06?
A: The LRD06 is designed for direct mounting on Schneider Electric LC1D09, LC1D12, LC1D18, LC1D25, LC1D32, and LC1D38 TeSys D contactors.
Q: What protection does the Schneider LRD06 provide?
A: The relay protects motors against overload, phase failure, and prolonged overcurrent conditions, helping extend motor life and reduce unplanned downtime.
